Since the 1980's, we have been in the pursuit of creating a broad and complete set of wholesome products line that is a sustainable and profitable; which incorporates designs and features that accommodate requisites of diverse industries. We, Elite Flow Co., Ltd., an ISO 9001:2000 company strive to offer products that reduce cost and raise output. We are a manufacturer, supplier and exporter of Stainless Steel 321 / 321H Forged Fittings, both are Titanium stabilised. Not only does ASTM A182 SS Forged 45° Socket Weld Elbows provides good insulation properties, they are weldable and manage to curb oxidation and its effects in the agricultural and food processing pipelines. The Titanium in WNR 1.4541/1.4878 SS Forged Screwed-Threaded Equal Tees bolsters an immunity to intergranular corrosion, as the Titanium reacts with Carbon to prevent Chromium compounds forming near grain boundary. Besides, the Titanium wards off disastrous carbide precipitation and reduces embrittlement.
UNS S32100 SS Forged Coupling are indispensable to the fire protection and process piping systems, as they have good mechanical properties and are ductile, and can be hardened through work hardening. Also We offer wide range of Stainless Steel ASTM A182 321 Forged Fittings such as SS 321 Forged Elbow, SS 321H Equal Tee, SS 321 Coupling, SS 321H Pipe Cap, SS 321 Union, SS 321 Bushing, SS 321 Plug, SS 321 Pipe Nipple, SS 321H Street Elbow.
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Threaded and Socket Weld Pipe Fittings
| Products | Size | |
| ASTM A182 SS 321 90° Elbows | ASTM A182 SS 321H 45° Elbows | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A182 SS 321H Forged Caps | ASTM A182 SS 321 Couplings | |
| ASTM A182 SS 321 Forged Tees | ASTM A182 SS 321H Unions | |
| ASTM A182 SS 321H Forged Cross | ASTM A182 SS 321 Inserts | |
| ASTM A182 SS 321 Forged Plug | ASTM A182 SS 321H Street Elbows | |
| ASTM A182 SS 321H Bushings | ASTM A182 SS 321 Pipe Nipple | |
SS 321 / 321H Forged Fittings Manufacturing Standards :
| ASTM A182 - ASME SA182 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| SS 321H | 1.4878 | S32109 | SUS 321H | X12CrNiTi18-9 |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 - 12.00 | 5(C+N) – 0.70 max |
| SS 321H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| Stainless Steel 321 Forged Pipe Fittings | Stainless Steel 321H High Pressure Forged Fittings |
| Stainless Steel 321H Socket Weld Fittings | Stainless Steel 321 Threaded Fittings |
| Stainless Steel UNS S32100 Socket Weld 90 Deg Elbow | Stainless Steel 321 Threaded 90 Deg Elbow |
| SS 321H Socket Weld 45 Degree Elbow Suppliers | ANSI 321 Stainless Steel Screwed 45 Degree Elbow |
| SS 321 Forged Tee Dealer | SS 321H Threaded Tee Exporter |
| SS 321 Socket Weld Cross Stockholder | Steel 321H Threaded / Screwed Cross Distributors |
| Stainless Steel SUS 321 Socket Weld Half Coupling | SS 321 Threaded Half Coupling Manufacturer |
| Stainless Steel DIN 1.4449 Full Coupling | Stainless Steel JIS 321H Coupling |
| Stainless Steel 321H Socket Weld Cap | Stainless 321 Screwed Cap |
| ANSI B16.11 SS 321 Socket Weld Union | SS 321H Threaded / Screwed Union Stockist |
| ASTM A182 SS 321 Screwed Hex Plug | ASME SA182 SS 321 Square Plug |
| Stainless Steel 321H Reducing Tee | 321 SS Threaded / Screwed Bushing |
| A182 SS 321 Hex Nipples | ASME SA182M SS 321H Swage Nipple |
| Steel 321H Threaded Street Elbow | SS 321 Threaded / Screwed Pipe Nipple |
| Stainless Steel 321 Socket weld Unequal Tee | SS 321H ASME B16.11 Threaded Unequal Tee |
ASTM A182 321 / 321H Forged Fittings are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A182 321 / 321H Stainless Steel Forged Pipe Fittings through a worldwide network of stock-keeping branches. These ASTM A182 321 / 321H Forged Fittings is use in various industries like :
A Wide Range Of the Best Quality 321 Stainless Steel Forged Fittings, ss 321 forged fittings price list, ss 321H forged fittings price, asme b16.11 fittings, 321 socket weld fittings dimensions pdf, threaded pipe fitting dimensions, socket weld pipe fittings dimensions, forged fittings definition, 3000 lb stainless steel forged fittings, forged fittings definition, forged steel fittings, forging process, hot forging process, drop forging process, ss 321H class 3000 fittings pressure rating, 150# stainless steel socket weld fittings, b16.11 pressure rating, ansi 3000 pressure rating, class 9000 fittings pressure rating, class 300 fittings pressure rating, 321H ss class 3000 pipe fittings pressure rating, asme b16.11 class 3000, class 6000 fittings, ss 321 pipe coupling dimensions, steel pipe fitting dimensions chart, galvanized pipe fittings dimensions, stainless steel 321 socket weld fittings Manufacturer, Supplier in China.
MIDDLE EAST Saudi Arabia |
AFRICA Nigeria NORTH AMERICA Usa |
EUROPE Russia |
ASIA India SOUTH AMERICA Argentina |
We are renowned & most acclaimed Source, Stock, Distribution, Manufacturer, Suppliers, Stockholder, Traders, Wholesaler, Dealer, Distributor, Importer & Exporter, Fabricator, Stockist of ASTM A182 321 / 321H Forged Fittings in Stainless Steel.
For More Information About ASTM A182 321 / 321H Stainless Steel Forged Fittings Please Call +86-577-66965398 or Send an Email to sales@eliteflowpiping.com
